EA040 Neutral Position Limit Switch
Model:
EA040
Brand:
NAMCO
Country of Origin:
India
Sample Available: No
For product pricing, customization or other inquiries:
View Contact Details
Saket Electronics
-
India
-
Website:
www.saketelectronics.co.in -
Location:
203-B, Sarjan Complex, Pratap Road, Dandia Bazar
Vadodara
Gujarat
Heavy Duty EA040 Series Limit Switch
The compact EA040 Series is a heavy duty, neutral position limit switch featuring two normally open circuits. This quick make, quick break, signle pole, double throw (SPDT) limit switch is engineered with Rocker Type SNAP-LOCK® Technology in a die-cast zinc housing for corrosion resistance. This series is available in standard and wide mounting. The EA040 Series is designed for applications where neutral position (mechanical trip of 7º to trip) is essential in operation. This limit switch series offers heavy duty butt contacts and heavy operating torque for severe industrial use. For hazardous location requirements, see EA880 Series Heavy Duty Limit Switch.
Technical Data
- Quick Make, Quick Break, Single Pole, Double Throw (SPDT)
- Rocker Type SNAP-LOCK® Technology
- Two normally open, Form “Z” contact arrangement
- Meets NEMA 1,4 & 13 requirements. Enclosure is watertight, oil & dust tight
- Contacts are made of silver alloy
- Temperature Range: -20º C to +90º C
- Operating lever is adjustable by 7º30' increments thru 173º
- Wiring space is ample for up to size 12 wire with easily accessible terminal screws
- Many different options available including: precious metal contacts; high temperature (0º C to 150º C) components and lubricants; low temperature (-40º C to 90º C) components and lubricants;and reverse shaft position
- Weight: Approx. 2.3 lbs
- For Ordering Information, see EA040 Series Specification Sheet
- Please note, operating levers are sold separately.
